Introduction 7
Encrypted DE110 User's Guide - Rev. A01 StorCase Technology, Inc.
Mode of Operation
There are two (2) modes of operation:
1. Encryption/Decryption Mode (default): Entire disk (including boot sector and OS)
is encrypted/decrypted with real-time performance. Refer to section "Electronic
Security Key" for further information.
2. Bypass Mode: Disables Encryption/Decryption mode.
To change the mode of operation, refer to section "Configuration Switches" for further
information.
Configuration Switches
NOTE: For quick reference, configuration switch settings are indicated on the pro-
vided carrier labels (refer to Figure 11 for further information).
Configuration switches are located at the rear of the carrier (Figure 4).
Refer to section "Configuration Switch Settings" on next page for further information.
Figure 4: Configuration Switches
Configuration
Switches
ON
1 2 3 4
