DE100i-A66 User's Guide - Rev. A00 StorCase Technology Inc.
Appendix A - Specifications/Dimensions 15
Appendix A - Specifications/Dimensions
Chassis Reliability/Maintainability
MTBF
500,000 Hours
MTTR 5 Minutes
Preventive
Maintenance
None
Electrical Specifications
Input +5V 65mA
+12V 400mA
Environmental Specifications
Operating Storage
Ambient Temperature -5° C to 50° C -45° C to 75° C
Relative Humidity (1) 10% to 80% 10% to 90%
Altitude -1000 to 50,000 ft -1000 to 50,000 ft
-304m to 15240m -304m to 15240m
Shock (2) 10g60g
(1) Non-condensing with maximum gradient of 10% per hour.
(2) 11 msec pulse width 1/2 sine wave.
Physical
Specifications
Carrier Receiving Frame
Height 1.68" (42.7mm) 1.70" (43.2mm)
Width 4.67" (118.6mm) 5.75" (146.1mm)
Depth 7.38" (187.5mm) 8.18" (207.8mm)
Weight 1.1lb (0.50kg) 1.25lb (0.57kg) (1)
(1) With carrier removed.
