3-20

Chapter 3: Configuring the Module

User’s Manual Pub. 0300274-01 Rev. A.0

Register Name Addr.

Comments

Default

R/W From PLC

R/W From Module

BAC_AO_31

0×5F8

0×5FF

BACnet Analog
Output tag 31

0

R

W

This block is for the first 32 BACnet Analog Output tag values.

BACnet Analog Output objects are made available via the BACnet stack as a
writable value that is then written by the module to the PLC. The data are then
copied into a user-specified PLC variable.

BACnet Analog Output 2 Block (0Ч600

– 0Ч6FF)

Register Name Addr.

Comments

Default

R/W From PLC

R/W From Module

BAC_AO_32

0Ч600

0Ч607

BACnet Analog
Output tag 32

0

R

W

BAC_AO_63

0×6F8

0×6FF

BACnet Analog
Output tag 63

0

R

W

This block is for the last 32 BACnet Analog Output tag values.

Module Block (0Ч00

– 0Ч1F)

3.5.4 Data Type Range

The maximum and minimum value of the tags is decided by the PLC data type
and it is also limited by data storage and conversion.

BOOL

TRUE or FALSE

SINT

-128 to 127

USINT

0 to 255

BYTE

0 to 255

INT

-32768 to 32767

UINT

0 to 65535

WORD

0 to 65535

DINT

-2147483648 to 2147483647

UDINT

0 to 429467295

Register Name

Addr.

Comments

Default

R/W From PLC

R/W From Module

MOD_ID_LO

0×00

Module ID

193

R

W

MOD_ID_HI

0×01

0

R

W

VENDOR_ID_LO

0×02

Vendor ID

58

R

W

VENDOR_ID_HI

0×03

0

R

W

PRODUCT_TYPE_LO

0×04

10

R

W

PRODUCT_TYPE_HI

0×05

0

R

W
