Page 29: Tructured

Chapter 3: Configuring the Module
3-11
User’s Manual Pub. 0300274-01 Rev. A.0
Example. In the above Tags list, you may change:
TO
3. To implement the changes, click Submit. The name changes to
__IO_EM_DO_123.
Section 3.4 Generating Structured Text
Rockwell Connected Component Workshop (CCW) software interfaces with the
BACnet module. Tag mapping is executed through CCW, which reads and writes
to the BACnet module using CCW structured text code . When you finish
mapping tags, you convert the tag information to structured text code.
1. To convert tag information to structured text code, add your tags using
the Tags dialog:
2. From the Tags dialog, click Generate Structured Text:
