Using your module in the ControlLogix System
Place your module in any slot of a ControlLogix modular, or modular
expansion chassis.
An analog I/O module translates an analog signal into, or from, a
corresponding digital representation which controllers can easily operate
on for control purposes.
A ControlLogix I/O module mounts in a ControlLogix chassis and uses a
Removable Terminal Block (RTB) to connect all field-side wiring.
Before you install and use your module you should have already:
· installed and grounded a 1756 chassis and power supply.
· ordered and received an RTB for your application.
Important: RTBs are not included with your module purchase.
Specify Allen Bradley Part Number:
1756-TBCH - 36 position screw terminals
1756-TBS6H - 36 position press terminals
Module Installation
and Removal
When installing the module in a chassis, it is not necessary to remove the
terminal blocks from the module. However, if the terminal blocks are
removed, use the write-on label located on the side of the terminal blocks
to identify the module location and type.
Preventing Electrostatic Discharge
This module is sensitive to electrostatic discharge.
ATTENTION: Electrostatic discharge can damage integrated
circuits or semiconductors if you touch backplane connector pins.
Follow these guidelines when you handle the module:
· Touch a grounded object to discharge static potential
· Wear an approved wrist-strap grounding device
· Do not touch the backplane connector or connector pins
· Do not touch circuit components inside the module
· If available, use a static-safe work station
· When not in use, keep the module in its static-shield box
