2

ControlLogix

Counter Module

Input Types

The 1756-CTR supports both AC and DC input signal types. The module
input type is configured on a channel pair basis. Each pair must be
configured for the same input type.

Hardware Features

The module fits into any single slot for I/O modules in a ControlLogix
modular system. The module has a unique generic profile which may be
configured using your RSLogix 5000 programming software.

The module utilizes one removable terminal block, that provides
connections for the eight input channels. The module is configured
through RSLogix 5000 software, defining input type, counter control and
signal filtering.

Table 1.1 Hardware Features

Hardware

Function

OK LED

Displays communication and fault status of the module

SYS LED

Displays a fault condition

Side Label (Nameplate)

Provides module information

Removable Terminal Block

Provides electrical connection to input devices

Door Label

Permits easy terminal identification

Self Locking Tabs

Secure module in chassis slot

Terminal Block Switch

Locks the RTB to the module.

Diagnostic LEDs

The module contains diagnostic LEDs that help you identify the source of
problems that may occur during power-up or during normal operation.
Power-up and diagnostics are explained in Chapter 7, Testing Your
Module
.

System Overview

The module communicates with the ControlLogix processor and receives
+5 Vdc and +24 Vdc power from the system power supply through the
parallel backplane interface. You may install as many counter modules in
the system as the power supply can support.

Channels (0 through 7) can receive AC or DC input signals. Input types
must be configured in channel pairs. Each channel reports both count data
and rate data in independent registers. Extended status information is also
available for each channel.
