SkyRC Hornet 60A ESC for Air - Manual

BRUSHLESS CONTROLLERS
FOR HELICOPTER & AIRCRAFT
1
Thanks for purchasing our HORNET series Electronic Speed Controller (ESC)
for helicopter & aircraft. This product is incorporates the latest SMT hardware
technological developments.
HORNET controllers also have the most intelligent, comprehensive software,
which means that this speed controller (or governor) is capable of operating
virtually any brushless motor currently on the market with optimum efficiency.
Please read through instructions entirely before attempting to operate with
these electronic devices.(including those who hate to read instructions!)
INTRODUCTION
Wiring Diagram
3
2
1
4
6
7
5
1. Receiver Cable, 3-pin:
- = negative . . . . . . . . black or brown
+ = positive . . . . . . . . red
s = signal . . . . . . . . . . white or orange
2. Battery Connection- Black Negative (-)
3. Battery Connection- Red Positive (+)
4. Motor connection a . . . . . Black
5. Motor connection b . . . . . Yellow,
6. Motor connection c . . . . . Red,
7. Heat Sink
+
-
