Rocktron Chameleon On-Line - Manual (Page 80)

77
Use the PARAMETER ADJUST control to choose the highest value that the parameter is not to exceed
through MIDI control changes. Step 9
ULIM C1 -2
After selecting a value for the upper limit, press the STORE button to save it. "STORED" will flash
briefly on the display. Step 10
STORED
Turn the PARAMETER SELECT control one step clockwise to access the Lower Limit parameter (for
PARA 1). Step 11
LLIM C1 - ∞
Use the PARAMETER ADJUST control to select the lowest value which the parameter is not to fall
below through MIDI control changes. Step 12
LLIM C1 -12
After selecting a value for the lower limit, press the STORE button to save it. "STORED" will flash
briefly on the display. Step 13
STORED
Selecting a lower limit value that is greater than the upper limit value will invert the response of the controller - i.e. the toe
position of the expression controller will provide the minimum value, while the heel position will provide the maximum
value.
NOTE: Steps 1-13 are repeated seven times for a total of eight controllers. To exit Controller Assign at
any time, turn either the PRESET or FUNCTION SELECT control. Only changes that have been
stored will be saved after exiting the Controller Assign function.
