18
POST EQ (EXPERT) Function
The POST EQ (EXPERT) function is available in all presets - regardless of which configuration is currently
recalled.
This function allows you shape the tone after it has passed through the distortion stage. These post-distortion
EQ parameters have a more dramatic effect on the overall tone than the pre-distortion parameters.
The PARAMETER SELECT control will allow you to access these POST EQ parameters:
The post-BASS LEVEL parameter allows you to cut or boost the low frequencies by 15dB
after the distortion stage.
The post-BASS FREQUENCY parameter allows you to select a center frequency be-
tween 63Hz and 500Hz to be cut or boosted by the post-BASS LEVEL parameter.
The post-BASS BANDWIDTH parameter determines (in octaves) the width of the se-
lected bass band.
The post-MID LEVEL parameter allows you to cut or boost the mid-band frequencies by
15dB after the distortion stage.
The post-MID FREQUENCY parameter allows you to select a mid-band center frequency
between 250Hz and 2kHz to be cut or boosted via the post-MID LEVEL parameter.
The post-MID BANDWIDTH parameter determines (in octaves) the width of the selected
mid-band.
The post-TREBLE LEVEL parameter allows you to cut or boost the high-band frequen-
cies by 15dB after the distortion stage.
The post-TREBLE FREQUENCY parameter allows you to select a high-band center
frequency between 1kHz and 8kHz to be cut or boosted via the post-TREBLE LEVEL
parameter.
The post-TREBLE BANDWIDTH parameter determines (in octaves) the width of the
selected high band.
The post-PRESENCE LEVEL parameter allows you to cut or boost another high-band
frequency by 15dB after the distortion stage.
The post-PRESENCE FREQUENCY parameter allows you to select a high-band center
frequency between 2kHz and 8kHz to be cut or boosted via the post-PRESENCE LEVEL
parameter.
The post-PRESENCE BANDWIDTH parameter determines (in octaves) the width of the
selected high band.
BASS LVL
BASS FREQ
BASS BW
MID LVL
MlD FREQ
MID BW
TREBLE LVL
TREBL FRQ
TREBLE BW
PRESENCE LVL
PRES FREQ
PRES BW
