Rocktron Chameleon On-Line User Manual

Page 79

Step 4

After selecting the desired controller number, press the STORE button to save the number for
the NUMB 1 parameter. "STORED" will flash briefly on the display.

STORED

Step 8

Turn the PARAMETER SELECT control one step clockwise to display the Upper Limit parameter (for
PARA 1).

ULIM C1

XXX

NOTE: The Chameleon allows you to select an upper and lower value limit which the parameter cannot

exceed. For example, if a parameter has a value range from -

∞

to 0dB, yet you would like the

range of the parameter to vary from only -12dB to -2dB, you may set a lower limit of -12 and an
upper limit of -2 via the Upper and Lower Limit parameters. When a parameter is stored in the
Controller Assign function (Step 7), the maximum parameter value is automatically stored as the
upper limit, while the minimum value is stored as the lower limit.

After selecting the parameter that you which to assign to a controller, press the STORE button
to save it. The Chameleon will flash "STORED" briefly.

Step 7

STORED

Step 6

Turn the PARAMETER ADJUST control to scroll through the available parameters for the
current configuration.

PARA1

REVERB LVL

Step 5

Turn the PARAMETER SELECT control one step clockwise to display the parameter that is
currently mapped to the NUMB 1 control number.

PARA1

OUTPUT
