6725
Semi-micro Calorimeter Instruction Manual
5-17
• Data Characters from
Balance. This setting is only
used when the generic
balance format is selected.
This value determines the
number of numeric data
characters (0-9 . + -) to
accept. Any additional
characters after this value and
before the string terminating
• Data Precision. This key
allows the user to establish
the number of digits to the
right of the decimal point that are passed from the balance handler.
• Transfer Timeout (seconds). This value determines how long the interface will
wait before giving up on a weight transfer. The value is entered in seconds.
• Balance Handler Strings. This key leads to a submenu that allows balance
template to be customized for unique balances or needs.
Log Balance to Display
Directs the incoming data stream from the balance to a display buffer. This function can
be used to determine the data format from an unknown balance type. The display buffer
is 40 characters in length. The balance must be forced to issue at least 40 characters
before the contents of the buffer are displayed.
Balance Port LoopBack Test
Initiates a loopback test on the port. A special loopback plug is required in order to
perform this test.
Further information on establishing communications for the Printer, Balance,
Network Interface, Bar Code Port and other Network Data Devices can be found in
the Installation section of this manual.
File Management Menu
Run Data File Manager:
This key activates the File Manager.
The File Manager is used to delete or
rename test report files. It is also used
to convert file types.
Format the SD Card:
This key provides access to a function
that will format the user installed SD
card in a manner that is compatible with
the CPU Boot loader. Formatting the
card this way is recommended prior to
installing any program update files on
the SD card.
