Mossberg MMR User Manual

Page 5

GENERAL INFORMATION AND MECHANICAL CHARACTERISTICS CONT.

Fig. 1 – MMR 5.56 Hunter (Right Side)

Fig. 2 – MMR 5.56 Hunter (Left Side)

Fig. 3 – MMR 5.56 Tactical w/ optional sights (Right Side)

Fig. 4 – MMR 5.56 Tactical w/ optional sights (Left Side)

SHELL DEFLECTOR

UPPER RECEIVER

EJECTION PORT

PIVOT PIN

HANDGUARD

MUZZLE

TAKEDOWN PIN

LOWER RECEIVER

MAGAZINE RELEASE BUTTON

MAGAZINE WELL

PICATINNY RAIL

BOLT CATCH

CHARGING HANDLE

FRONT SWIVEL STUD

TRIGGER

PISTOL GRIP

REAR SLING MOUNT

BUTTSTOCK

SAFETY

SELECTOR

LEVER
