Gamma 1-16 LSC&
Gamma 2-16 LSC&
10 Technical data
88
Version 04/2013, Rev. 1.1 of 16/12/2013 • sb
Translation of the original operating manual
Pos: 221 /20 0 Ch rist/3 61 G T-BA L abo r-Pilot (PROJEKTE)/G am ma 1 -16 _2- 16 LSCplus/1 00 Tec hnisch e Dat en/1 00 Tec hnisch e Dat en G am ma 1 -16 /2- 16 LSC plus= == === == == === == == == === == == === == == @ 15\ mo d_1 3578 121 076 07_ 68.d ocx @ 789 32 @ 1 @ 1
10 Technical data
Manufacturer: Martin Christ
Gefriertrocknungsanlagen GmbH
An der Unteren Söse 50
37520 Osterode
Germany
Type: Gamma 1-16 LSC
plus
Gamma 2-16 LSC
plus
Part number: 102210 102211
Performance data Gamma 1-16 LSC
plus
Gamma 2-16 LSC
plus
Ice condenser
- capacity:
- performance:
- temperature:
- chamber volume:
16 kg max
12 kg / 24 h max
approx. –60°C
approx. 30 l
16 kg max
12 kg / 24 h max
approx. –85°C
approx. 30 l
Temperature of the ice condenser
during hot-gas defrosting: approx. 60°C approx.60°C
Possible shelf temperatures
( process A): freezing and drying
inside the ice condenser chamber
approx. –25°C to +60°C approx. –50°C to +60°C
Possible shelf temperatures
( process B): drying outside the
ice condenser chamber Room temperature to +60°C Room temperature to +60°C
Max. shelf surface area
( process A): drying inside the
ice condenser chamber
drying in injection vials with sealing
under vacuum or nitrogen
atmosphere inside the ice
condenser chamber
5 shelves, 200 mm each
A
total
=0.155 m 2
2 shelves, 250 mm each
A
total
=0.09 m 2
5 shelves, 200 mm each
A
total
=0.155 m 2
2 shelves, 250 mm each
A
total
=0.09 m 2
Max. shelf surface area
( process B):
drying outside the ice condenser
chamber
drying in injection vials with sealing
under vacuum or nitrogen
atmosphere outside the ice
condenser chamber
drying in round bottom flasks
8 shelves, Ø 375 mm each
A
total
=0.88 m 2
4 shelves, 250 mm each
A
total
=0.18 m 2
12 pieces bzw. 24 pieces
8 shelves, Ø 375 mm each
A
total
=0.88 m 2
4 shelves, 250 mm each
A
total
=0.18 m 2
12 pieces bzw. 24 pieces
