Rear View
15
16
17
18
19
20
21
22 23 24
25
26
27
28
29
30
31
32
34
33
15. Charging status indicator 25. LCD segment display
16. Recording status indicator 26. Microphone
17. Up button 27. Shutter button
18. Down button 28. Stop button
19. OK button 29. Mini HDMI interface
20. Left arrow button 30. USB interface
21. Right arrow button 31. TF card slot
22. Recording status indicator 32. Menu button
23. Charging status indicator 33. TFT display
24. Speaker 34. Playback button
Description of Indicators
Position
Status
Red indicator Green indicator Blue indicator
Front cover(1)
top cover(1)
TFT display(1)
Front cover(1)
top cover(1)
TFT display(1)
bottom side(2)
Front cover(1)
Startup
Flash once and
then Stay on
/ /
Video
recording
/ Flash slowly /
Audio
recording
/ Flash slowly /
shooting
Stay on Flash once /
Card full Stay on Stay on /
Charging
(switched off)
Flash slowly / /
Fully charged
(switched off)
Stay on / /
Low-battery
indicator
Flash fast for 5s and
then auto power off
/ /
Data
transmission
Stay on / flash slowly
Wi-Fi on Stay on / flash slowly
When powering down the screen, the TFT display indicators will be lit. You
can long-press the Shutter button to turn on/off the screen.
