4
1) Liquid Crystal Display (LCD).
2)
CAL key, to enter and exit calibration mode.
RCL key (alternate function), to enter and exit memory recall.
3) CFM/GLP key, to confirm calibration selection, different setup values
or to display Good Laboratory Practice information.
4) ºC key, to manually increase temperature value or other parameters.
TC key (alternate function), to view temperature coefficient value.
5) ºC key, to manually decrease temperature value or other parameters.
ATC key (alternate function), to select EC temperature compensation mode.
6) SETUP key, to enter/exit SETUP mode.
LOCK key (alternate function), to freeze current EC range on the LCD.
7) RANGE key, to select measurement range (EC, TDS, NaCl), switch to
focused data in SETUP or toggle between standard value and
temperature during calibration.
8) LOG/CLR key, to store a value into memory, or to select to delete log
records.
9) ALT key, to select alternate function.
10) ON/OFF switch.
11) Power supply socket.
12) USB connector.
13) EC probe connector.
Front Panel
Rear Panel
FUNCTIONAL DESCRIPTION
