9
8£
8
1. Fuse holder
2. Power supply terminals
3. Recorder output terminals
4. Connections to the transmitter
REAR PANEL HI 8510T
1. Fuse holder
2. Power supply terminals
3. Recorder output terminals
4. Connections for Pt100 temperature sensor
5. BNC socket for pH electrode
FUSE
FUSE
ELECTRODE
INPUT
PT100
mA OUT
+
-
220 11
0 L
1
2
3
4
5
REAR PANEL HI 8510E
Unplug the instrument from the power
supply before replacing the fuse. Unplug the instrument from the power
supply before replacing the fuse.
