Buhl LyteBoard IWB User Guide V.12/7/09
Page 28 of 43
www.buhl-ind.com
4.2.2 Whiteboard orientation
It is necessary to fix position of Whiteboard to make pen or fingertip coincidence before
using for the first time. There is no need to reorientation unless change the environment.
Orientation method: First start the Whiteboard , right click this icon ( )in the
lower right corner and choose [Orientate Whiteboard], then you will see the full screen
with a white anchor point at the top left corner (P 4-1). Click this white anchor point
with finger or other tools, identified automatically by the PC. After that there will be
other three same anchor points respectively in the top right corner (P 4-2), lower right
corner (P 4-3), lower left corner (P 4-4), follow the method above , finally finish the
whole Orientation.
P 4-1
