3. Installation and Connection
3.1 Whiteboard Installation
3.1.1 Wall-mounted Installation
Accessories list:
Installation steps:
1. wall-mounted pieces Installation
(1)Check the height and location of the Whiteboard installation, then line out the center position of
wall-mounted pieces(
P
3-1) on the wall.(
P
3-2)
P
3-1
name
total
use of quantity
wall-mounted pieces
2
2
expansion screw
12
8
screw
（3.5*16KA）
12 8
