P
3-2
(2)To drill holes at the marked position of the screw on the wall with a drill bit (diameter
6 mm), then put the expansion screws into the holes.
(3)Fix the wall-mounted pieces onto the wall with eight screws (3.5*1 KA). Finish
wall-mounted pieces installation.
2. Whiteboard Installation
Aim the holes of the Whiteboard (P 3-3) at the
wall-mounted pieces, and then hang the
Whiteboard onto the wall-mounted pieces.
P 3-3
Notice:
1. Ensure that the wall is firm enough to bear the Whiteboard.
2. Make sure that the two wall-mounted pieces have same horizontal height and with a
h
floor
1170mm
