GoDEX EZDT4 - Manual (Page 9)

3
2
1
1. Platen Cover
2. Label Sensor
3. Platen Roller
1
3
2
4
1. Power Socket
2. USB Port
3. Fan-Fold Label Insert
4. Serial Port (RS-232)
1 2
1. Bottom Case Cover
2. Hang Holes
EZ-DT-2/EZ-DT-4 User’s Manual
