3-3. EZ-DT-2 t Module Installation
Ethernet Ca
Etherne
ble 1.8M 1
2
Module Connection Wire
3 Bracket
4 Ethernet module
5 Ethernet Back Panel
6 Bracket Screw*2
7 Secure Screw*2
【Note】
Please make sure that anti-static precautions
are adopted during the installation.
1
2
3
5
4
6
7
1. Make sure the power is off and the power
cable is unplugged. Place the printer onto
a smooth surface and flip the whole printer
side down.
the bottom case screws as
ated in figure.
unit up
2.
Unscrew
indic
3. Remove the Front Cover Plate.
4. ment and the top Lift the middle compart
cover up.
5. Unplug the power connector on the
mainboard.
6. Remove the middle compartment and the
top cover together with the mainboard.
7. ompartment and the
ainboard.
Turn over the middle c
top cover to the left side of m
