3-4. EZ-DT-4 Ethernet Module Installation
1 Ethernet module
2 Ethernet Back Panel
3 Module Connection Wire
4 Secure Screw*1
5 Ethernet Cable 1.8M
1
2
3
5
4
【Note】
Plea e make sure that anti-static precautions
dopted during the installation.
s
are a
1. power is off and the power
cable is unplugged. Place the printer onto
a smooth surface and flip the whole printer
unit upside down.
2.
Unscrew bottom case screws as indicated
in figure.
Make sure the
3. ver Open Button and open the
top cover.
Press the Co
1
1
2
2
4. Remove the Front Cover Plate.
5. Lift the middle compartment and the top
cover up.
6. Loosen hexagonal screws on both sides of
. Push the mainboard slightly to the direction
ndicated in figure.
the
RS-232 port.
7
that i
8.
Remove standard Back Panel from
printer.
