2-2. Label Roll Core Switch
1. Pull the Label Roll
Holder to the
topmost and lift the
Label Roll Core
upward.
2.
Turn the Label Roll
Core outward as
the figure shows.
3.
Whirl the Label Roll
Core back to the
original position.
1” Core
A. When the lock hole
of Label Roll Core
is on upper side, it
applies to 1” core.
B.
When the lock hole
of Label Roll Core
is on lower side, it
applies to 1.5” core.
【Note】
You can also distinguish
it by the index on the
Label Roll Core as
shown in figure.
1.5” Core
