1-3. Communication Interface
Serial Interface
Serial Default
Setting
:
9600 baud rate､no parity､8 data bits､1 stop bit､XON/XOFF protocol and
RTS/CTS。
RS232 HOUSING (9-pin to 9-pin)
DB9 SOCKET DB9 PLUG
--- 1 1 +5V,max 500mA
RXD 2 2 TXD
TXD 3 3 RXD
DTR 4 4 N/C
GND 5 5 GND
DSR 6 6 RTS
RTS 7 7 CTS
CTS 8 8 RTS
RI 9 9 N/C
PC PRINTER
【Note】The total current output from serial port can not exceed 500mA.
USB Interface
Connector Type : Type B
PIN NO. 1 2 3 4
FUNCTION VBUS D- D+ GND
Internal Interface
UART1 wafer Ethernet module
N.C 1 1 N.C
TXD 2 2 RXD
RXD 3 3 TXD
CTS 4 4 RTS
GND 5 5 GND
RTS 6 6 CTS
E_MD 7 7 E_MD
RTS 8 8 CTS
E_RST 9 9 E_RST
+5V 10 10 +5V
GND 11 11 GND
+5V 12 12 +5V
