Page 25
6 Distance to Home Point (Unit: m) 15
The angle of turning to the Home Point
(Unit: deg)
7 Power battery current (Unit: A) 16 Attitude table
8 Flight mode 17
Relative position of Home Point (Icon
in the middle position when the
aircraft is around Home Point.)
9
Current latitude & longitude of the
plane (Format: dddmm.mmm)
Flight mode instruction
Name Introduction
3D Attitude Stabilized Mode
NAV Hovering Mode
RTL Auto Return To Launch Mode(RTH)
15.1 Via Remote Control And OSD Overlay Menu Set
FY-41AP
Attention: Please be cautious when you into the OSD overlay menu to adjust
the FY-41AP parameters. We strongly suggest you do not install propeller to do the
1 ) You can not execute Combination Stick Commands (CSC) to start the motor
when you in the OSD overlay menu. If you want to start the motor please exit the
OSD setting menu.
2 ) You can not enter the OSD setting menu after you execute Combination Stick
Commands (CSC) to start the motor. If you want to enter the OSD setting menu
please wait the FY-41AP into the state before execute Combination Stick
Commands (CSC).
(1) Activate the OSD setup menu: switch " Hovering Mode " to the
To Launch Mode(RTH)" 6 times in SW1, between two switching it has to be less than 3
seconds, the process is as follows: Hovering Mod→Auto Return To Launch Mode(RTH)
→Hovering Mod →Auto Return To Launch Mode(RTH) →Hovering Mod →Auto Return To
Launch Mode(RTH) →Hovering Mod →Auto Return To Launch Mode(RTH) →Hovering
Mod →Auto Return To Launch Mode(RTH) →Hovering Mod→Auto Return To Launch
Mode(RTH). This will activate OSD setup menu interface.
(2) Move Elevator stick to the project you want to set.
(3) Move aileron stick to the project you want to set.
(4) Please put elevator stick to SAVE, after your setting.Through the stick of
ailerons carried out to save the action, when saving, "SAVE" will flicker for two seconds,
the end of the flashing, been saved successful.
