Page 10
Connect the USB data cable to
UART1 port to firmware upgrade
for FY-41AP control module
Connect the USB data cable to
UART2 port to firmware upgrade
for OSD module
Data link wire
Connect the FY-602 data radio to
UART1 port
Vibration absorbing pads
(dampers),use for FY-41AP
vibration damping installation.
6. Main Module Installation
6.1 FY-41AP Module Installation
 While installing, please keep FY-41AP horizontal and as close
as possible to the "Centre of gravity" (COG) of the aircraft.
The module‘s orientation can be changed by FY-GCS
(Ground Control Station) system: arrow to front (default), back, left or right. Please
reset the ―install orientation‖ after you changed the install orientation.
 Efficient anti-vibration components are very important and to be used when installing.
You can use the included ‗vibration absorbing dampers‘ or your DIY equipment.
Please note: For Nitro planes, flying without using efficient ‗anti vibration damper‘s‘,
will lead to FY-41AP working abnormally.
 The better the damping installation is, the better attitude control and GPS hovering
functions are.

Each modules installation to a suitable position is conducive to further enhance the
