Light Source 53
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS
TEC Fabry-Perot Laser Specifications a
Model 02BLC 03BLC 04BLC 23BLC 34BLC
Wavelength b (nm) 1310 +20/—30 1550 ± 20 1625 ± 15 1310 +20/—30 1550 ± 20
1550 ± 20 1625 ± 15
Spectral width (rms) c (nm) 2 5 10 2/5 5/10
Output power (dBm) * 0 * 0 * —4 * —1 * —4
Stability d (dB) (D/2)
15 min ± 0.003 ± 0.003 ± 0.01 ± 0.005 ± 0.01
8 h ± 0.03 ± 0.03 ± 0.05 ± 0.05 ± 0.05
Temperature sensitivity e (dB) ± 0.25 ± 0.25 ± 0.25 ± 0.25 ± 0.25
Modulation 270 Hz, 1 kHz, 2 kHz (50 % duty cycle)
Model 02ORL 03ORL 04ORL 23ORL 34ORL
Wavelength b (nm) 1310 +20/—30 1550 ± 20 1625 ± 15 1310 +20/—30 1550 ± 20
1550 ± 20 1625 ± 15
Spectral width (rms) c (nm) 2 5 10 2/5 5/10
Output power (dBm) * —2 * —2 * —6 * —3 * —6
Stability d (dB) (D/2)
15 min ± 0.01 ± 0.01 ± 0.01 ± 0.01 ± 0.01
8 h ± 0.03 ± 0.03 ± 0.03 ± 0.05 ± 0.03
Temperature sensitivity e (dB) ± 0.25 ± 0.25 ± 0.25 ± 0.25 ± 0.25
SURFACE-EMITTING LED SPECIFICATIONS a
Model 01C/D 02C/D 12C 12D
Wavelength b (nm) 850 ± 25 1300 +45/—60 850 ± 25 850 ± 25
1300 +45/—60 1300 +45/—60
Spectral width (FWHM) f, g (nm) 50 145 50/145 50/145
Output power (dBm) * —17/* —14 * —21/* —17 * —18/—22 * —15/—18
Stability d (dB) (D/2)
15 min ± 0.003 ± 0.003 ± 0.005 ± 0.005
8 h ± 0.03 ± 0.03 ± 0.05 ± 0.05
Temperature sensitivity e (dB) ± 0.4 ± 0.4 ± 0.4 ± 0.4
Modulation 270 Hz, 1 kHz, 2 kHz (50 % duty cycle)
IQS-2100 GENERAL SPECIFICATIONS
Size (H x W x D) 125 mm x 36 mm x 282 mm (4 15/16 in x 1 7/16 in x 11 1/8 in)
Weight 0.5 kg (1.1 lb)
Temperature
Operating 0 °C to 40 °C (32 °F to 104 °F)
Storage —35 °C to 70 °C (—31 °F to 158 °F)
Relative humidity 0 % to 95 % non-condensing
