Data display – EXFO IQS-2100 Light Source for IQS-500/600 User Manual
Page 20
Getting Started with Your Light Source
14
IQS-2100
Starting the Light Source Application
Data Display
In addition to the Control Center, the main window also contains the data
display, where the source status indicator, as well as values for wavelength,
modulation, and attenuation controls are shown (see figure below).
Source
status
indicator
Signal wavelength
Attenuation value
indicator
Modulation value
indicator
