EXFO FTB-5500B PMD Analyzer User Manual
Page 60
Managing Results
52
FTB-5500B
Viewing Statistics
To view statistics for a single fiber:
1. From the button bar, click Storage. Ensure that the results you intend
to use are displayed on the list. When you are done, click Exit Storage.
2. From the main window, click the Tools tab. Click Single-Fiber Statistics.
Statistics for the first fiber on the list appears in the grid.
You can specify which measurements must be taken into account for
statistics by selecting or clearing the corresponding boxes.
The Select All button allows you to quickly select all the boxes.
The Select Valid button selects all the measurements that do not
exceed the specified thresholds.
Statistics values for the selected fiber
Selected fiber
Measurements
associated with
selected fiber
