Managing Results
44 FTB-5500B
Viewing Acquisition Results and Information
To view specific portions of the graph:
³
Select the desired type of zoom that will be applied when you will
press on the FTB-500 screen (or click on the graph with your mouse).
³
Select the desired mode (pan, zoom type, etc.).
To toggle between the available graph backgrounds:
Click the
button to select the desired background.
To return to the original graph view:
Click the
button to revert to most significant graph area.
Viewing Acquisition Results and Information
The application allows you to view current results and information directly
or reload data from existing files.
The application provides:
³
a window presenting details for the measurement that you specify
³
a window giving you an overview of all of the available measurements
Move view area
(pan)
Automatic zoom in
Zoom in on a
selected area
Automatic zoom out
Vertical zoom
Horizontal zoom
Horizontal and vertical zoom
