EXFO FTB-5500B PMD Analyzer User Manual
Page 45
Operating the Polarization Mode Dispersion Analyzer
Polarization Mode Dispersion Analyzer
37
Setting Up Hardware for Measurements
To set up hardware for measurements using the FLS-110P Light
Source:
1. Clean and verify the quality of the connectors being used.
2. Connect the device under test (DUT) as shown below.
3. Turn on the FLS-110P unit.
4. Press CW to ensure that it is emitting in CW mode.
DUT
FTB-5500B
PMD
