Polarization Mode Dispersion Analyzer 101
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS
Wavelength range (nm) 1260 to 1675 (O to U band)
Measurement range (ps) 0 to 115
Sensitivity a (dBm) –45
Measuring time (s) 4.5 (for any PMD value)
Absolute uncertainty (strong mode coupling) b (ps) ± (0.020 + 2 % of PMD)
Allows measurement through EDFA Yes (above 120 EDFAs)
GENERAL SPECIFICATIONS
Temperature
operating 0 °C to 40 °C (32 °F to 104 °F)
storage –40 °C to 70 °C (–40 °F to 158 °F)
Relative humidity 0 % to 93 % non-condensing
Size (H x W x D) (module only) 9.6 cm x 7.6 cm x 26.0 cm (3 3 / 4 in x 3 in x 10 1 / 4 in)
Weight (module only) 1.5 kg (3.4 lb)
Notes
a. Typical, for C band. May be increased with averaging. With the FLS-5800, the typical dynamic range is 47 dB.
b. For C band, assuming averaging over all states of polarization.
