Opening files, Mportant – EXFO FOT-5200 Coarse Spectrum Analyzer User Manual
Page 30

Setting Up and Operating your FOT-5200
24
FOT-5200
Opening Files
The
key acts as a backspace button.
If you want to exit without saving, press the ESC key until all of the file
name letters have been deleted. Press once more on the ESC key. Press
ENT when you are done.
Note: You can save up to 100 files.
Opening Files
Press OPEN (
)to access the menu
that calls the measured result of optic
power for each channel in the form of
text and graphs. Press OPEN again to
select the file you want and press ENT,
the file is displayed.
Note: If the opened file is in graph mode you
can use the Graph/TEXT button to
change to text mode.
I
MPORTANT
If you try to save the file using a name and that it already exists,
you will be notified and the file is not saved.
