Battery charger – EXFO FOT-5200 Coarse Spectrum Analyzer User Manual
Page 12

Safety Information
6
FOT-5200
Battery Charger
Turn off the product’s power using the Power button.
Do not operate the product with the cover removed.
Do not operate a product suspected of being damaged. Have it
checked by a certified professional technician.
Do not touch exposed circuits. Do not touch exposed connections or
parts when power is being supplied.
Do not use in damp environments.
Keep the surface of product clean and dry.
Battery Charger
A rechargeable battery is installed inside the measuring instrument, and
this charger module has a standard 24-pin charger port.
When the charger module is connected to the measuring instrument, the
circular picture on the connecting part points to the bottom of the
instrument.
The LED on the charger module indicates different situations depending on
its color and state:
Color
Status
Red, ON (continuous)
The charger module is in charging
mode.
Green, ON (continuous)
Charge complete. Ready to use.
Red, Blinking
Error or damage to battery.
