Setting Up and Operating your FOT-5200
22
FOT-5200
Graph Data Display
Graph Data Display
If you press the
button, a bar graph is displayed for each channel
value in an easy to read format.
You can use this feature in CWDM SCAN, USER SCAN and SCAN ALL, and
the following shows how it is displayed.
In the case of pressing Graph/Text in CWDM SCAN mode.
In the case of pressing Graph/Text in user-defined channel mode.
In the case of pressing Graph/Text in scanning all channels.
