Eurocom L29xN All-in-One LCD PC User Manual
Page 91

Upgrading The Computer
Upgrading the Optical Device (Model A) 5 - 9
5
5.
Carefully remove the rear cover
and set it aside.
6.
The optical device will now be visible at point
on the mainboard.
7.
Remove screws
-
, and disconnect cable
, from the optical device.
8.
Remove the optical device, and remove the screws in order to separate the optical
device from the bracket.
9.
Reverse the removal procedures to install the new optical device.
12
Figure 5 - 9
Model A
Rear Case
Removal
Figure 5 - 10
Model A
Optical Device
Removal
13
12
13
14
16
17
14
15
16
17
