Eurocom X8100 Leopard - Manual (Page 128)

Upgrading The Computer
6 - 18 Upgrading the System Memory (RAM) - 2
6
17. Snap the LED cover module down at the top of the module at points & .
18. Push the LED cover module down on the left side at point , and then slide the
module to the right (as illustrated) and snap down to secure it in place.
19. Replace the screws on the bottom of the computer (see Figure 6 - 12 ).
20. Restart the computer to allow the BIOS to register the new memory configuration
as it starts up.
Figure 6 - 20
LED Cover Module
Slide to the Right &
Snap Down
22 23
24
22 23
24
