Upgrading The Computer
6 - 14 Upgrading the System Memory (RAM) - 2
6
3. Turn the computer over, open the Lid/LCD, and carefully (a cable is connected to
the underside of the LED cover module) unsnap up the LED cover module from
point
on the right.
4. Lift up the LED cover module and disconnect cable .
3
3
Figure 6 - 13
LED Cover Module
Removal
Figure 6 - 14
LED Cover Module
Cable Disconnect
4 5
4
5
5
