ASSEMBLY INSTRUCTIONS
Inspection of Parts: Take a look at each of the parts bags and compare to the Parts List (on pages 1 &
2). Be sure that nothing was damaged during shipment and handling. Contact Elenco
®
Electronics if you
have any problems (phone number is on the back of this manual).
-7-
Remote Control Transmitter
Transmitter Antenna
9V Battery Slot
(Alkaline recommended)
Note: Screw in tight.
1
2
Battery Contact,
Battery Contacts
+ ,
Battery Contact, +
Battery Contact, +
Battery Cover
Back of
Bottom Frame
NOTE: Slide
the contacts into
the slots and then
fold back the tabs on
the top side to hold
in place.
Switch Placement
Insert the switch onto the posts. Then,
secure by melting the plastic posts with
a soldering iron.
Switch
Posts
Snap In Tab
Red Wire
Black Wire
White Wire
