Elenco Radio Controlled Car Soldering - Manual (Page 3)

BAG 3 - SCREWS (6AK870B1E)
Qty. Description Part #
5 Screws 0.4” x 0.1” (10mm x 2.6mm) 640101
4 Screws 0.3” x 0.1” (8mm x 2.6mm), 0.15” head 640102
3 Screws 0.3” x 0.1” (8mm x 2.6mm), 0.2” head 640102E
BAG 4 - HARDWARE (6RCC7KB4E)
Qty. Description Part #
2 Rear Springs 680023
1 Front Spring 680024
2 Shock Absorber Springs 680025
1 Rear Rod 0.8” x 0.075” 610808
(20mm x 2mm)
1 Steering Alignment Wire/Spring 6RCC7K11
2 Front Wheel Bars 6RCC7K12E
1 Battery Contact, + 6RCC7K13E
1 Battery Contact, – 6RCC7K14E
2 Battery Contact, + – 6RCC7K15E
1 Battery Contact, – + 6RCC7K16E
1 Switch, on/off 6RCC7K18E
1 Rear Axle 662019E1
1 Transmitter Antenna 484010E
BAG 5 - WIRES
(6RCC7KB5E)
Qty. Description Part #
1 Light Bulb, with wires attached 6RCC7K21
1 4” wire, red 6RCC7K22
1 4” wire, blue 6RCC7K23
1 4” wire, black 6RCC7K24
1 4” wire, green 6RCC7K25
1 4” wire, yellow 6RCC7K26
1 4” wire, orange 6RCC7K27
1 4” wire, white 6RCC7K29
1 Solder Roll 6RCC7K30
BAG 6 - COVERS (6RCC7KB6E)
Qty. Description Part #
1 Front Section Cover 626018E1
1 Rear Section Cover 626019E
1 Steering Bar 626023E
1 Battery Cover 6RCC7K31E
2 Front Wheels 6RCC7K43E
2 Rear Wheels 626019E2
1 Top Light Bulb Cover 626022
BAG 7 - GEARS (6RCC7KB7E)
Qty. Description Part #
2 Locators for Rear Wheels 626019E3
2 Turning Posts for Front Wheels 6RCC7K34E
1 Steering Alignment Post 6RCC7K36E
1 Gear, Rear Wheels Axle 626019E4
1 Steering Motor Bracket 626018E2
1 Gear, middle of rear section 610809
BAG 8 - MOTORS (6RCC7KB8E)
Qty. Description Part #
1 Driving Motor (larger) 6RCC7K39
1 Steering Motor (smaller) 6RCC7K40E
1 0.01
µ
F Disc Capacitors 241031
1 0.1
µ
F Disc Capacitors 251010
2 Motor Gear 6RCC7K37
PACKAGED SEPARATELY
Qty. Description Part #
1 Bottom Frame 6RCC7K42E
1 Top Frame 6AK870TFE
1 Car Antenna 484011E
1 Remote Control Transmitter, 6AK870TAE
Assembled Except for Antenna
1 Decorative Decals (1 Sheet) 720063E
-2-
You may have been given different screws from
those specified here (and usually some spares).
Contact Elenco
® if it is not clear which to use.
Important Note:
There is only one operating frequency for this kit
(27MHz). If you have several units then each
transmitter can control every car.
You may
purchase a conversion kit to change the
operating frequency to 49MHz, use the order
form on page 34.
This conversion requires
replacing 14 parts in the transmitter (which
comes pre-assembled here) and 7 part
substitutions on the car circuit board (that you
will assemble here).
Caution: Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
