PARTS IDENTIFICATION
-2-
RESISTORS
CAPACITORS
SEMICONDUCTORS
Resistor
50k
Ω
Potentiometer
with Switch
Discap
Electrolytic
Radial
Tuning
Diode
Transistor
LM-386 IC
Antenna Assembly
Coil
Coil
Plastic Holders
Ferrite Core
Color Dot
Knob (pot)
Earphone Jack with Nut
Knob (dial)
Radio Stand
COILS
MISCELLANEOUS
Label, Dial Knob
Battery
Holder
Earphone
OR
Speaker Pad
Speaker
IC Socket
Test
Point Pin
Screw
2-56 x 1/4”
Screw
M2.5 x 3.8mm
Nut
2-56
Screw
2-56 x 5/16”
