-1-
PARTS LIST
If you are a student, and any parts are missing or damaged, please see instructor or bookstore.
If you purchased this kit from a distributor, catalog, etc., please contact Elenco
® Electronics (address/phone/e-
mail is at the back of this manual) for additional assistance, if needed. DO NOT contact your place of purchase
as they will not be able to help you.
RESISTORS
Qty. Symbol Value Color Code Part #
1 R14 10
Ω 5% 1/4W
brown-black-black-gold 121000
1 R13 47 Ω 5% 1/4W yellow-violet-black-gold 124700
1 R8 100 Ω 5% 1/4W brown-black-brown-gold 131000
1 R10 470
Ω 5% 1/4W
yellow-violet-brown-gold 134700
1 R6 1k
Ω 5% 1/4W
brown-black-red-gold 141000
1 R12 2.2k
Ω 5% 1/4W
red-red-red-gold 142200
2 R3, R11 3.3k
Ω 5% 1/4W
orange-orange-red-gold 143300
1 R9 10k Ω 5% 1/4W brown-black-orange-gold 151000
1 R2 12k Ω 5% 1/4W brown-red-orange-gold 151200
1 R5 27k Ω 5% 1/4W red-violet-orange-gold 152700
1 R7 39k
Ω 5% 1/4W
orange-white-orange-gold 153900
1 R1 56k
Ω 5% 1/4W
green-blue-orange-gold 155600
1 R4 1M
Ω 5% 1/4W
brown-black-green-gold 171000
1 Pot/SW1 50k
Ω (nut & washer)
192522
CAPACITORS
Qty. Symbol Value Description Part #
1 C1 Variable Tuning 211677
1 C15 .001 μF Discap (102) 231036
2 C3, C10 .01
μF Discap
(103) 241031
5 C2, C5, C7, C8, C9 .02
μF or .022μF
Discap (203) or (223) 242010
1 C16 .047
μF Discap
(473) 244780
3 C4, C11, C12 10
μF
Electrolytic Radial (Lytic Capacitor) 271045
1 C6 100 μF Electrolytic Radial (Lytic Capacitor) 281044
2 C13, C14 470 μF Electrolytic Radial (Lytic Capacitor) 284743
SEMICONDUCTORS
Qty. Symbol Description Part #
1 D1 1N4148 Diode 314148
3 Q1, Q2, Q3 2N3904 Transistor NPN 323904
1 U1 LM-386 Integrated Circuit 330386
COILS
Qty. Symbol Description Part #
1 L2 Oscillator (red dot) 430057
1 T1 IF (yellow dot) 430260
1 T2 IF (white dot) 430262
1 T3 Detector (black dot) 430264
1 L1 Antenna with Holders 484004
MISCELLANEOUS
Qty. Description Part #
1 PC Board 517037
1 Battery Holder 590096
1 Speaker 590102
1 Knob (pot) 622017
1 Knob (dial) 622030
1 Earphone Jack with Nut 622130 or 622131
1 Radio Stand 626100
1 Earphone 629250
3 Screw 2-56 x 1/4” 641230
1 Screw 2-56 x 5/16” 641231
Qty. Description Part #
3 Screw M2.5 x 3.8mm 641310
4 Nut 2-56 644201
1 IC Socket 8-Pin 664008
8 Test Point Pin 665008
1 Label, Dial Knob 720421
1 Manual 752550
1 Speaker Pad 780128
1 Wire 4” 814920
1 Solder Lead-Free 9LF99
Punch out one antenna shim from the front flap of the box.
**** SAVE THE BOX THAT THIS KIT CAME IN. IT WILL BE USED ON PAGES 24 & 29. ****
