Qty. ID Name Symbol Part # Qty. ID Name Symbol Part #
1
1 Motor
Fan 6SCM1
6SCM1F
1 Adjustable Resistor 6SCRV
1
Red Light Emitting
Diode (LED)
6SCD1 1 100 Ω Resistor 6SCR1
1
Green Light Emitting
Diode (LED)
6SCD2 1 1K Ω Resistor 6SCR2
1 0.02 μF Capacitor 6SCC1 1 5.1k Ω Resistor 6SCR3
1 0.1 μF Capacitor 6SCC2 1 10k Ω Resistor 6SCR4
1 10 μF Capacitor 6SCC3 1 100k Ω Resistor 6SCR5
1 100 μF Capacitor 6SCC4 1
High Frequency
Integrated Circuit
6SCU5
1 470 μF Capacitor 6SCC5 1 PNP Transistor 6SCQ1
1 Variable Capacitor 6SCCV 1 NPN Transistor 6SCQ2
1 Three-spring Socket 6SC?Q
-4-
D2
C1
C2
U5
R5
R4
R3
C4
C3
Q1
Note: If you have model RS-303, then there are additional part lists in your other project manuals.
Parts List
(Colors and styles may vary) Symbols and Numbers
D1 R1
R2
Q2
RV
CV
C5
M1
?Q
Important: If any parts are missing or damaged in shipping, DO NOT RETURN TO RADIO SHACK. Call toll-free 1-800-THE-SHACK.
