Quick Installation Guide

EEV-EX20 Quick Installation Guide 21

2.3.17

(Module Codec) Audio Amp. Left/ Right out channel out

(CN5/ CN6)

Signal

PIN

AMP_LOUT+/ AMP_ROUT+

1

AMP_LOUT-/ AMP_ROUT-

2

2.3.18

(Carrier board codec) S/PDIF connector (CN8)

Signal

PIN

S/PDIF in

1

S/PDIF out

2

CN5

CN6
