EEV-EX20
10 EEV-EX20 Quick Installation Guide
Connectors
Label Function Note
JCOM1 Serial Port 2 in RS-232 mode 5 x 2 header, pitch 2.54mm
JDIO1 General purpose I/O connector
10 x 2 header, pitch
2.54mm
JIR1 IrDA connector 5 x 1 header, pitch 2.54mm
JLPC1 LPC connector 8 x 2 header, pitch 2.0mm
JLVDS1 LVDS connector
DIN 40-pin wafer, pitch
1.25mm
JRS422/485 Serial port 2 in RS-422/485 mode 3 x 2 header, pitch 2.0mm
JTV1 TV out connector 3 x 2 header, pitch 2.54mm
JUSB1 USB connector 4 & 5 5 x 2 header, pitch 2.54mm
KB/MS1 PS/2 keyboard & mouse connector
TTL1 Serial port 1 connector (TTL level) 5 x 2 header, pitch 2.0mm
TTL2 Serial port 2 connector (TTL level) 5 x 2 header, pitch 2.0mm
PCI1/2 PCI slot 1/2
PCIE1/2 PCIE slot 1/2
PEC1 Mini PCI-e slot
PCE2 PCI express card slot
PWRBTN1 Power button connector
RESET1 Reset button connector
SATA1/2/3/4 Serial ATA connector1/2/3/4
WDT1 Watch dog in
WLED1 Mini PCIe LED connector 3 x 2 header, pitch 2.54mm
XTX X1/2/3/4 XTX connector 1/ 2/ 3/ 4
