EBM-CX700 Series
68 EBM-CX700 Series User’s Manual
Item Options Description
Onboard Serial Port 1
Onboard Serial Port 2
Disable
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
AUTO
Select an address and corresponding interrupt
for the first and second serial ports.
Onboard Parallel Port
Disabled
378/IRQ7
278/IRQ5
3BC/IRQ7
Select a matching address and interrupt for the
physical parallel (printer) port.
Parallel Port Mode
SPP
EPP
ECP
ECP+EPP
Select an operating mode for the onboard
parallel port. Select Compatible or Extended
unless you are certain both your hardware and
software support EPP or ECP mode.
EPP Mode Select
EPP1.9
EPP1.7
Select EPP port type 1.7 or 1.9.
ECP Mode Use DMA
1
3
Select a DMA channel for the port.
Watch Dog Function
Enabled
Disabled
This item allows you to decide enable/disable
Watch Dog function
Watch Dog Timer Select 1~255Min This option will determine watch dog timer.
Onboard Fast IR
Enabled
Disabled
This item allows you to decide enable/disable
the onboard fast IR
Fast IR IRQ 11,5,3,4
This item shows you the value of Fast IR IRQ.
The value:11, 5, 3, 4
Fast IR DMA 6, 5
This item shows you the value of Fast IR DMA.
The value: 6, 5
