EBM-CX700 Series
12 EBM-CX700 Series User’s Manual
1.5 System Specifications
System
CPU Onboard VIA Eden V4 500 (1W), up to Eden 1G (3.5W)
BIOS Award 512 KB Flash BIOS
System Chipset VIA CX700M
I/O Chip VIA VT1211
System Memory
One 200-pin DDR2 SODIMM socket, supports up to 1GB DDR2
400/533 SDRAM
SSD
One CF socket by IDE secondary slave channel supports Type I / II
Compact Flash Card.
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor
Monitoring system temperature, voltage, and cooling fan status. Auto
throttling control when CPU overheats
Expansion 1 x Mini PCI slot onboard
I/O
MIO 2 x EIDE, 2 x SATA, 2 x RS-232, 1 x K/B & Mouse
IrDA 115k bps, IrDA 1.0 compliant
USB 6 x USB 2.0 ports
DIO 16-bit General Purpose I/O for DI and DO
Display
Chipset
VIA CX700M with integrated 2D and 3D Graphics engine supporting
MPEG-4 accelerator, MPEG-2 decoder and WMV9 Video acceleration
Display Memory Supports 32 / 64 / 128 MB Frame Buffer sizes
Resolution
CRT mode: 2048 x 1536 @ 32 bpp (85 Hz)
LVDS mode: 1600 x 1200 @ 16 bpp (60 Hz)
VGA/LCD Interface AGP 4X VGA/LCD interface
LVDS Dual-channel 18/24-bit LVDS
DVI CX700M, DVI resolutions up to UXGA (1600 x 1200)
TV-out TV resolutions up to 1920x1080i (CX700M)
