User ’s Manual
ECM-PNV User ’s Manual 67
Item Option Description
DVMT Mode Select
Fixed Mode,
DVMT Mode
Displays the active system
memory mode.
DVMT/ FIXED Memory
64MB,
128MB,
Maximum DVMT
Specifies the amount of DVMT/
FIXED system memory to allocate
for video memory.
Boot Display Device
VBIOS
CRT,
LVDS,
CRT+LVDS (Default)
This option selects the display
device the system uses when it
boots.
Flat Panel Type 640 x 480,
800 x 600,
1024 x 768,
1024 x 600,
1024 x 576,
800 x 480,
1280 x 720,
1280 x 768,
800 x 600,
1024 x 600,
1024 x 768
1024 x 768,
1024 x 768,
1280 x 800,
1280 x 600,
1366 x 768
This item specifies the flat panel
PC type being used.
Spread Spectrum Clock
[Disabled]
Disabled (Default)
Enabled
This item allows you to enable or
disable spread spectrum clock.
LCD Backlight Mode
PWM
DC
This item configures the settings
for Backlight control
PWM value [128] 0 ~ 255
PWM clock [24Mhz] 24M or 180khz
PWM PreScale 090
PWM type Pushpull (Default)
OpenDrain
DC Value [32] 0 ~ 63
