ECM-PNV
20 ECM-PNV User ’s Manual
Connectors
Label Function Note
BAT Battery connector 2 x 1 wafer, pitch 1.25 mm
COM1 Serial port 1 connector D-sub 9-pin, male
CPU_FAN CPU fan connector 4 x 1 wafer, pitch 2.54 mm
J422/485_1 Serial port 2 in RS-422/485 mode 3 x 2 header, pitch 2.0 mm
JTOUCH Touch panel connector 9 x 1 header, pitch 2.0 mm
JAUDIO Audio connector 6 x 2 header, pitch 2.0 mm
JCOM2 Serial port 2 connector 5 x 2 header, pitch 2.0 mm
JDIO General purpose I/O connector 10 x 2 header, pitch 2.0 mm
JLPC (Reserved for debug) 7 x 2 header, pitch 2.0 mm
JSPI SPI connector 3 x 2 header, pitch 2.0 mm
JUSB2 USB connector 5 x 2 header, pitch 2.0 mm
JUSB3 USB connector 5 x 2 header, pitch 2.0 mm
JLVDS LVDS connector 2 x 10 header, pitch 1.25mm
JBKL LCD inverter connector 5 x 1 wafer, pitch 2.0mm
LAN1 RJ-45 Ethernet connector
LAN2 RJ-45 Ethernet connector
LED2 LED connector
PWR Power connector 2 x 2 wafer, pitch 4.2 mm
PWR_SB 5VSB connector in ATX 3 x 1 wafer, pitch 2.54 mm
S_PWR1 SATA power connector 2 x 1 wafer, pitch 2.0 mm
SATA1 Serial ATA connector 1
SATA2 Serial ATA connector 2
RSTBTN Reset button
USB1 USB connector Double Deck
VGA VGA connector D-sub 15-pin, female
