2.1.2 Setup the IP address from Ethernet port
In addition to VT100 interface, we also provide a Network Setup Software tool as below for the network
settings to the IP serial console.
The operation procedures are as follows:
1. Run the software tool IP serial console IPCS_Setup.exe
2. Click Search Devices to find out the IP serial console devices on the network. After few seconds, the MAC
addresses of found devices will show on Device MAC address field.
3. Select the MAC address on Device MAC address, then click Query Device to get the device configuration
on the right pane.
4. If you want to change the settings. Enter the Super user name & password. Change the settings on the right
pane. Then click Update Device. The new settings will be save to the IP serial console unit, then the unit will
be reboot automatically.
Access IP serial console
Using the HTTP protocol and entering the confi gured IP address of IP serial console into the web browser
to remote access the IP serial console.
With successful connection to IP serial console, the login page will show as below, then key in the default user
name & password when connecting to the IP serial console unit, the IP serial console system (web server,
Telnet server or SSH server) will prompt user to enter the user name and password in order to access to the
system.
There are two levels of access privileges:
User Default Access
Name Password Privileges
root root Full access
(user define) (user define) Limit access to serial port
The administrator can add or remove a user easily via
the web pages of System administration.
For details, please visit the link below :
http://www.austin-hughes.com/support/utilities/cyberview/IPCS_Setup.exe
P.5
< 2.1 > Device Setup CS-116
